| Power | 6.0W |
| Working Voltage | 5.0V |
| Nominal Operating Cell Temperature (NOCT) | 25℃ |
a. Use low iron tempered glass with a thickness of 4.2mm, with a light transmittance of over 92%. Frameless design.
b. One-year warranty. Normal service life is 6 years or more (excluding corrosion conditions). Junction box waterproof rating IP65, can withstand snow load ≤ 2200Pa, wind load ≤ 3200Pa.
c. Normal operating temperature of the component is 25℃, temperature range -30℃ to +85℃. System withstand voltage DC1000, light intensity greater than 100000LUX. Environmentally friendly non-explosive product.
d. Applicable direction: It is recommended to install the battery panel component facing south (in the northern hemisphere) or north (in the southern hemisphere), with an inclination angle of 30°.
e. If there is an overvoltage or overcurrent (i.e., electrical parameters) that is higher than the basic level, it is a normal and qualified product. This product is suitable for single pieces with a power consumption voltage of approximately 4.2V for power generation and charging. It is suitable for outdoor charging conversion use. It belongs to custom product category. Positive and negative terminal junction boxes are uniformly configured and there are no requirements for placement positions.
f. The surface is glossy and transparent, suitable for normal sunlight conditions and normal strong sunlight irradiation. Conversion rate of the battery cell is 19.0% to 20.0%. Conversion rate of the component is 17.5% to 18.5%. The electrical performance is the main criterion, and there are no requirements for panel appearance or not following the material orientation. The array shown in the diagram is only for reference!
FAQ of Mini Solar Panel
1.Before quotation, what kind of information should be clearly required?
The size of solar panel with its voltage, Current/Power and purchasing quantity..2.What kinds of minisolar panels are available from MARS ROCK?
3.What information must I give you if I need professional propose on producing Mini solar panels?
1）Battery Voltage:4. Which type of Mini solar panel is more suitable for me?
For Mini solar panel is customized product, so buyers need to consider the following factors to choose the correct type:
Mono solar panel with slightly better efficiency, so in the limited installation place, Mono can generate higher power than poly but with litter higher cost too.
Normally it's FR4 fiber glass backer material, to make the solar panel stronger; but also there are options for paper backer, which is easy to get dampened by the rain, or wet weather, or semi fiber glass;.
PET is lighter,more consistant appearance and thinner than Epoxy Resin mini solar panel. But EXpoy Resin with more harder, thicker protection on its surface. So even in blizzard weather, it can still have better protection and is not easy to be damaged at first.
